Fixed Shadow Beam Anchor Fall Protection

Miller 8815-24 Shadow Lite is a fixed aluminum beam anchor for flange sizes from 12 to 24 inches wide.

Key Features
-Connects to a variety of I and H beam flanges from 3 inches (76mm) to 24 inches (610mm) wide and up to 2 1/2 inches (63mm) thick.
-Stainless steel support shaft
-Aluminum foot ends
-Maximum working load 400 pounds (181.4 kilograms)
-5000 pound minimum tensile strength

Recommended Industries/Use

Construction
Steel and Metals

Hazards

Fall from height

Regulations

Meets all applicable OSHA, ANSI and CSA standards

Specifications
Foot Ends Aluminum
Support Shaft Stainless Steel
Hand-Retractable Plunger Stainless Steel
D-Ring Attachment Plated, Drop Forged Steel
and Stainless Steel
Hardware Steel Minimum Tensile strength
All hardware meets ASTM (50) fifty-hour salt spray test requirements.
Technical
Max Working Load 400 lbs (181.4 kg)
Minimum Tensile Strength 5000 lbs. (22kN)
Fits Flange Sizes 12” to 24” (305mm to 610mm)
Weight 13.65lbs (6.19kg)
