Fill-Rite 6-40 GPM 4-Digit Mechanical Fuel Transfer Meter
Fill-Rite 6-40 GPM 4-Digit Features:
- The 901C is a mechanical fuel transfer metre with four digits. This metre has NPT threads and is designed to register 6-40 gallons per minute with an accuracy of +/- 2%. There are no additional installation components included with this model.
- Designed with nutating disc technology that is capable of removing rust and small debris that clog and damage other metres.
- Cast-Aluminum Construction – Built to last with cast-aluminum construction that is designed for optimal durability and lifetime corrosion resistance.
- Extreme Accuracy – measures fuel within +/- 2% accuracy, ensuring that your records are as accurate as possible.
- Low-Volume Applications – Four-digit counter registers flow rates between 6-40 GPM and up to 999.9 gallons per batch, ideal for large fuel containers on heavy equipment.
- lifespan Monitoring – A seven-digit, non-resettable counter monitors the total volume transferred over the meter’s lifespan.
SAR 1,555.88
CompareFill-Rite 6-40 GPM 4-Digit Description:
Fill-Rite’s 900 Series mechanical fuel transfer metres are suitable for high-volume applications, with a batch capacity of up to 999 gallons.
Flowrate Range 6-40 GPM
Inlet / Outlet Thread Size (in.) NPT / NPT
Accuracy (+/- %) 2 %
Repeatability (+/- %) 0.38 %
Display Type Mechanical
Display Digits 4
Totalizer
Pulse Output
Compatible Fluids Mineral Spirits, Diesel, Gasoline, Kerosene, Heptane, Hexane
Operating Temperature Range -15 – 150°F / -26 – 66°C
Max Operating Pressure (PSI) 50
Assembled Product Height x Width x Depth (in.) N/A x N/A x 5.5
Assembled Product Weight (lbs.) 7.5
Package Height x Width x Depth (in.) 7.38 x 7.25 x 10.5
Gross Weight (lbs.) 8.100 lbs
Less Than Load (LTL) Freight Yes
Brand
Fill-Rite
